Bronze mesh - warm option for architectural and design applications
C220 Commercial bronze has a rich and pleasing color lending it to a wide range of architectural and design applications and projects. Our bronze mesh can be paired with design perforated metal and other meshes to create a layered design. Our online catalog of bronze mesh products range from coarse, stiff panels that can be used in cabinetry and design to very fine, smooth mesh that can be used for sifting or insect screens. Some notable patterns include our 22080, Doppio, Miscela, and 22104 designs, these patterns are woven in house and are available in other materials and finishes with the exception of Miscela.
View more | Image | Spec. sheet | Mesh count Number of holes per linear inch running across width of mesh x number of holes per linear inch running along length of mesh. | Clear opening Actual spacing between consecutive wires in inches. | % Open area The percent open area relates to the amount of flow or light that will pass through the mesh. | Lbs/sf Weight of material per square foot. | Applications/notes Typical applications or uses for mesh. |
---|
View more | Image | Spec. sheet | Mesh count Number of holes per linear inch running across width of mesh x number of holes per linear inch running along length of mesh. | Clear opening Actual spacing between consecutive wires in inches. | % Open area The percent open area relates to the amount of flow or light that will pass through the mesh. | Lbs/sf Weight of material per square foot. | Applications/notes Typical applications or uses for mesh. |
---|---|---|---|---|---|---|---|
Ferrier Miscela 2 x 2 weavemesh
Ferrier Miscela 2 x 2 weavemesh Mesh count: Miscela 2 x 2 Wire diameter(s): 0.104" Clear opening: 0.396" % Open area: 62.7 Lbs/sf: 1.50 Applications/notes: millwork, railing, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
Miscela 2 x 2 | 0.396" | 62.7 | 1.50 | millwork, railing, design | ||
Ferrier Doppio BRO75 weavemesh
Ferrier Doppio BRO75 weavemesh Mesh count: Doppio BRO75 Wire diameter(s): 0.080" Clear opening: 0.590" % Open area: 61.9 Lbs/sf: ~1.15 Applications/notes: millwork, cabinetry, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
Doppio BRO75 | 0.590" | 61.9 | ~1.15 | millwork, cabinetry, design | ||
Ferrier bronze 2 x 2 mesh x .104 weavemesh
Ferrier bronze 2 x 2 mesh x .104 weavemesh Mesh count: 2 x 2 mesh Wire diameter(s): 0.104" Clear opening: 0.396" % Open area: 62.7 Lbs/sf: 1.59 Applications/notes: millwork, cabinetry, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
2 x 2 mesh | 0.396" | 62.7 | 1.59 | millwork, cabinetry, design | ||
Ferrier bronze 2 x 2 mesh x .080 weavemesh
Ferrier bronze 2 x 2 mesh x .080 weavemesh Mesh count: 2 x 2 mesh Wire diameter(s): 0.080" Clear opening: 0.420" % Open area: 70.6 Lbs/sf: 0.917 Applications/notes: millwork, cabinetry, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
2 x 2 mesh | 0.420" | 70.6 | 0.917 | millwork, cabinetry, design | ||
Ferrier bronze 4 x 4 mesh x .047 weavemesh
Ferrier bronze 4 x 4 mesh x .047 weavemesh Mesh count: 4 x 4 mesh Wire diameter(s): 0.047" Clear opening: 0.203" % Open area: 65.9 Lbs/sf: 0.637 Applications/notes: millwork, cabinetry, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
4 x 4 mesh | 0.203" | 65.9 | 0.637 | millwork, cabinetry, design | ||
Ferrier bronze 8 x 8 mesh x .028 weaveme
Ferrier bronze 8 x 8 mesh x .028 weaveme Mesh count: 8 x 8 mesh Wire diameter(s): 0.028" Clear opening: 0.097" % Open area: 60.2 Lbs/sf: 0.454 Applications/notes: millwork, cabinetry, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
8 x 8 mesh | 0.097" | 60.2 | 0.454 | millwork, cabinetry, design | ||
Ferrier bronze 20 x 20 mesh x .016 weavemesh
Ferrier bronze 20 x 20 mesh x .016 weavemesh Mesh count: 20 x 20 mesh Wire diameter(s): 0.016" Clear opening: 0.034" % Open area: 46.2 Lbs/sf: 0.380 Applications/notes: millwork, cabinetry, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
20 x 20 mesh | 0.034" | 46.2 | 0.380 | millwork, cabinetry, design | ||
Ferrier bronze 40 x 40 mesh x .010 weavemesh
Ferrier bronze 40 x 40 mesh x .010 weavemesh Mesh count: 40 x 40 mesh Wire diameter(s): 0.010" Clear opening: 0.015" % Open area: 36.0 Lbs/sf: 0.31 Applications/notes: millwork, cabinetry, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
*.pdf*.dwg | 40 x 40 mesh | 0.015" | 36.0 | 0.31 | millwork, cabinetry, design | |
Ferrier PHOBRO 100 x 100 mesh x .0045 weavemesh
Ferrier PHOBRO 100 x 100 mesh x .0045 weavemesh Mesh count: 100 x 100 mesh Wire diameter(s): 0.0045" Clear opening: 0.0055" % Open area: 30.3 Lbs/sf: 0.16 Applications/notes: PHOSPHOR BRONZE MATERIAL, millwork, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
*.pdf*.dwg | 100 x 100 mesh | 0.0055" | 30.3 | 0.16 | PHOSPHOR BRONZE MATERIAL, millwork, design | |
Ferrier PHOBRO 150 x 150 mesh x 0026 weavemesh
Ferrier PHOBRO 150 x 150 mesh x 0026 weavemesh Mesh count: 150 X 150 mesh Wire diameter(s): 0.0026" Clear opening: 0.0041" % Open area: 37.8 Lbs/sf: 0.080 Applications/notes: PHOSPHOR BRONZE MATERIAL, millwork, design
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
*.pdf*.dwg | 150 X 150 mesh | 0.0041" | 37.8 | 0.080 | PHOSPHOR BRONZE MATERIAL, millwork, design |
The Miscela design weavemesh pattern is a combination of stainless steel and C220 bronze, The Ottawa Art Gallery and Nightingale Restaurant projects highlight its asthetic nature. The Doppio to 40 x 40 mesh are C220 commercial bronze. The finer bronze mesh (100 x 100 and 150 x 150) are made from phosphor bronze, an alloy that includes tin for increased corrosion resistance and strength. Our bronze mesh patterns that are woven in house (22080, 22104, Doppio, and Miscela) are available in 4’ x 4’ panels which can be sheared to size while the finer patterns (4 x 4 mesh to 150 x 150 mesh) are offered in 3’ x 100’ rolls which can also be cut to size (please note width cannot exceed 3’). Please note there is a 3’ x 3’ minimum with longer custom sizes available. It is worth noting that bronze mesh will darken as it ages. Depending on personal preference, the rugged and dull looks of aged bronze can be more appealing than the unmarred, pristine look of new bronze. The exact same characteristics can be seen in copper and brass mesh. For more information about the specifications and measurements of our products, spec. sheets with drawings are available on our website product pages above.
If you have any questions about our bronze mesh or any other products, please call or email us.
