Copper mesh - a lovely red hue
At Ferrier Wire + Design Metals we offer a wide range of copper mesh for use in industrial, architectural and design applications. C110 Copper is 99.9% pure, has that lovely red copper hue and if left untreated and exposed to the elements the copper will initially turn black, then eventually (many years down the road) the material will turn green. The brightness can be brought back with the use of an abrasive. Please note the copper products we supply are not coated with any sort of lacquer or finish to prevent the natural color from changing over time. The 22080 copper mesh pattern is woven in house and available in 4’ x 4’ sheets and custom sizes are also available.
| View more | Image | Spec. sheet | Mesh count Number of holes per linear inch running across width of mesh x number of holes per linear inch running length of mesh. If numbers have “ denotation e.g. 3/4” x 3/4”, it means 3/4” from the centre of one wire to the centre of the next wire in both directions | Clear opening Actual spacing between consecutive wires in inches. | % Open area The percent open area relates to the amount of flow or light that will pass through the mesh. | Lbs/sf Weight of material per square foot. | Applications/notes Typical application or uses of product. |
|---|
| View more | Image | Spec. sheet | Mesh count Number of holes per linear inch running across width of mesh x number of holes per linear inch running length of mesh. If numbers have “ denotation e.g. 3/4” x 3/4”, it means 3/4” from the centre of one wire to the centre of the next wire in both directions | Clear opening Actual spacing between consecutive wires in inches. | % Open area The percent open area relates to the amount of flow or light that will pass through the mesh. | Lbs/sf Weight of material per square foot. | Applications/notes Typical application or uses of product. |
|---|---|---|---|---|---|---|---|
 |
Ferrier copper 2 x 2 mesh x .080 weavemesh
Ferrier copper 2 x 2 mesh x .080 weavemesh Mesh count: 2 x 2 mesh Wire diameter: 0.080" Clear opening: 0.420" % Open area: 70.6 Lbs/sf: 0.917 Applications/notes: millwork, cabinetry, birdscreen
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
2 x 2 mesh | 0.420" | 70.6 | 0.917 | millwork, cabinetry, birdscreen | |
|
Ferrier copper 4 x 4 mesh x .047 weavemesh
Ferrier copper 4 x 4 mesh x .047 weavemesh Mesh count: 4 x 4 mesh Wire diameter: 0.047" Clear opening: 0.203" % Open area: 65.9 Lbs/sf: 0.637 Applications/notes: millwork, cabinetry, roofing
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
4 x 4 mesh | 0.203" | 65.9 | 0.637 | millwork, cabinetry, roofing | |
|
Ferrier copper 8 x 8 mesh x .028 weavemesh
Ferrier copper 8 x 8 mesh x .028 weavemesh Mesh count: 8 x 8 mesh Wire diameter: 0.028" Clear opening: 0.097" % Open area: 60.2 Lbs/sf: 0.454 Applications/notes: millwork, cabinetry, roofing, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
8 x 8 mesh | 0.097" | 60.2 | 0.454 | millwork, cabinetry, roofing, filtration | |
|
Ferrier copper 10 x 10 mesh x .025 weavemesh
Ferrier copper 10 x 10 mesh x .025 weavemesh Mesh count: 10 x 10 mesh Wire diameter: 0.025" Clear opening: 0.075" % Open area: 56.3 Lbs/sf: 0.455 Applications/notes: millwork, cabinetry, roofing, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
10 x 10 mesh | 0.075" | 56.3 | 0.455 | millwork, cabinetry, roofing, filtration | |
|
Ferrier copper 12 x 12 mesh x .023 weavemesh
Ferrier copper 12 x 12 mesh x .023 weavemesh Mesh count: 12 x 12 mesh Wire diameter: 0.023" Clear opening: 0.060" % Open area: 51.8 Lbs/sf: 0.466 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
12 x 12 mesh | 0.060" | 51.8 | 0.466 | millwork, cabinetry, filtration | |
|
Ferrier copper 14 x 14 mesh x .020 weavemesh
Ferrier copper 14 x 14 mesh x .020 weavemesh Mesh count: 14 x 14 mesh Wire diameter: 0.020" Clear opening: 0.051" % Open area: 51.0 Lbs/sf: 0.411 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
14 x 14 mesh | 0.051" | 51.0 | 0.411 | millwork, cabinetry, filtration | |
|
Ferrier copper 16 x 16 mesh x .018 weavemesh
Ferrier copper 16 x 16 mesh x .018 weavemesh Mesh count: 16 x 16 mesh Wire diameter: 0.018" Clear opening: 0.045" % Open area: 50.7 Lbs/sf: 0.381 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
16 x 16 mesh | 0.045" | 50.7 | 0.381 | millwork, cabinetry, filtration | |
|
Ferrier copper 16 x 16 mesh x .011 weavemesh
Ferrier copper 16 x 16 mesh x .011 weavemesh Mesh count: 16 x 16 mesh Wire diameter: 0.011" Clear opening: 0.052" % Open area: 67.9 Lbs/sf: 0.139 Applications/notes: EMI/RFI shielding, insect screen
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
16 x 16 mesh | 0.052" | 67.9 | 0.139 | EMI/RFI shielding, insect screen | |
|
Ferrier copper 20 x 20 mesh x .016 weavemesh
Ferrier copper 20 x 20 mesh x .016 weavemesh Mesh count: 20 x 20 mesh Wire diameter: 0.016" Clear opening: 0.034" % Open area: 46.2 Lbs/sf: 0.380 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
20 x 20 mesh | 0.034" | 46.2 | 0.380 | millwork, cabinetry, filtration | |
|
Ferrier copper 22 x 22 mesh x .015 weavemesh
Ferrier copper 22 x 22 mesh x .015 weavemesh Mesh count: 22 x 22 mesh Wire diameter: 0.015" Clear opening: 0.031" % Open area: 45.0 Lbs/sf: 0.369 Applications/notes: EMI/RFI shielding, millwork, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
--- | 22 x 22 mesh | 0.031" | 45.0 | 0.369 | EMI/RFI shielding, millwork, filtration |
|
Ferrier copper 24 x 24 mesh x .014 weavemesh
Ferrier copper 24 x 24 mesh x .014 weavemesh Mesh count: 24 x 24 mesh Wire diameter: 0.014" Clear opening: 0.028" % Open area: 44.2 Lbs/sf: 0.351 Applications/notes: EMI/RFI shielding, millwork, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
24 x 24 mesh | 0.028" | 44.2 | 0.351 | EMI/RFI shielding, millwork, filtration | |
|
Ferrier copper 30 x 30 mesh x .012 weavemesh
Ferrier copper 30 x 30 mesh x .012 weavemesh Mesh count: 30 x 30 mesh Wire diameter: 0.012" Clear opening: 0.021" % Open area: 40.8 Lbs/sf: 0.325 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
30 x 30 mesh | 0.021" | 40.8 | 0.325 | millwork, cabinetry, filtration | |
|
Ferrier copper 40 x 40 mesh x .010 weavemesh
Ferrier copper 40 x 40 mesh x .010 weavemesh Mesh count: 40 x 40 mesh Wire diameter: 0.010" Clear opening: 0.015" % Open area: 36.0 Lbs/sf: 0.305 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
*.pdf*.dwg | 40 x 40 mesh | 0.015" | 36.0 | 0.305 | millwork, cabinetry, filtration |
|
Ferrier 50 x 50 mesh .009 weavemesh
Ferrier 50 x 50 mesh .009 weavemesh Mesh count: 50 x 50 mesh Wire diameter: 0.009" Clear opening: 0.011" % Open area: 30.3 Lbs/sf: 0.314 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
*.pdf*.dwg | 50 x 50 mesh | 0.011" | 30.3 | 0.314 | millwork, cabinetry, filtration |
|
Ferrier copper 80 x 80 mesh x .0055 weavemesh
Ferrier copper 80 x 80 mesh x .0055 weavemesh Mesh count: 80 x 80 mesh Wire diameter: 0.0055" Clear opening: 0.007" % Open area: 31.4 Lbs/sf: 0.187 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
80 x 80 mesh | 0.007" | 31.4 | 0.187 | millwork, cabinetry, filtration | |
|
Ferrier copper 100 x 100 mesh x .0045 weavemesh
Ferrier copper 100 x 100 mesh x .0045 weavemesh Mesh count: 100 x 100 mesh Wire diameter: 0.0045" Clear opening: 0.0055" % Open area: 30.3 Lbs/sf: 0.159 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
*.pdf*.dwg | 100 x 100 mesh | 0.0055" | 30.3 | 0.159 | millwork, cabinetry, filtration |
|
Ferrier copper 200 x 200 mesh x .0021 weavemesh
Ferrier copper 200 x 200 mesh x .0021 weavemesh Mesh count: 200 x 200 mesh Wire diameter: 0.0021" Clear opening: 0.0029" % Open area: 33.6 Lbs/sf: 0.063 Applications/notes: millwork, cabinetry, filtration
Size
Material/finish
Price
Delivery Options
Quantity
Custom: For quantities greater than 5 pieces of one item or custom sizes larger than those noted above (our minimums) please complete and submit the following: Custom Size
Material/finish
Description (if applicable)
Quantity
|
*.pdf*.dwg | 200 x 200 mesh | 0.0029" | 33.6 | 0.063 | millwork, cabinetry, filtration |
Copper mesh can be used for the following applications:
- Millwork and cabinetry
- Electromagnetic shielding
- Insect screen
- Paper making
- Various design applications
In addition to the copper mesh products listed above, we have a new design pattern available called Voliere which is woven from copper wire. This pattern can be viewed by clicking here. Another copper design product offered is our textura Vellen pattern which is a light gauge piece of textured sheet metal available in solid copper. More details on our Vellen copper sheet texture are available here.
Many of our Ampliato patterns and perforated metal panels can be plated to bright copper, satin copper, and antique copper finishes. Ferrier has recently added a copper vein finish as a finishing option, this finish offers a slightly speckled, textured finish option. Our Parrilla SS250 pattern is available with Lammin Kupfer (antique copper) finish which is a popular pattern for cabinetry and other design applications.
If you have any questions about our copper weavemesh or any other products, please call or email us. To view a range of our copper weavemesh for use in architectural and design applications as well as projects that have utilized these products, please click here.
